Solenoid 2/2 Valve NO double blocking SUN T-8A
This FLeX Series solenoid-operated 2-way, 2-position cartridge is a direct-acting directional poppet valve. Available in either normally open or normally closed configurations, these valves feature a pressure-balanced design, low leakage, and allow flow or blocking in both directions. This cartridge can be installed directly into a cavity in the end of many of Sun's pilot operated and ventable valves to provide integrated pilot control.
Varenummer:
DTAF-MHN
Pakke str.:
0 pcs
Min. bestillingsenhed er:
1 pcs
Aktivering
Manual override, Solenoid
Antal veje/positioner
2/2
Cavity
T-8A
Flow Nominel
28 lpm
Forureningsgrad maks.
15/13/11 - ISO 4406
Manuel betjening
Yes
Mærke navn
Sun Hydraulics
Olieviskositet anbefalet
2,8 - 380 cSt
Pakningsmateriale
NBR
Temperatur maks.
+110 °C
Temperatur min.
-30 °C
Tilspændingsmoment
27 - 33 Nm
Tryk maks.
350 bar
Ventiltype
NC - Normally closed
Package size
0 pcs
Barcode
5715803521229
Gross weight
Kg
Net weight
Kg
Country of origin
usa
This FLeX Series solenoid-operated 2-way, 2-position cartridge is a direct-acting directional poppet valve. Available in either normally open or normally closed configurations, these valves feature a pressure-balanced design, low leakage, and allow flow or blocking in both directions. This cartridge can be installed directly into a cavity in the end of many of Sun's pilot operated and ventable valves to provide integrated pilot control.
