SIT24-N-15.85
|
Sitex hub, drilled ø15,85 H7 |
4,0 mm |
35 mm |
2.1 daNm |
28 |
|
SIT24-N-19
|
Sitex hub, drilled ø19 H7 |
6,0 mm |
35 mm |
2.1 daNm |
28 |
|
SIT24-N-24
|
Sitex hub, drilled ø24 H7 |
8,0 mm |
35 mm |
2.1 daNm |
28 |
|
SIT24-N-GR1
|
Sitex hub, drilled gr1 (1:8) |
2,4 mm |
35 mm |
2.1 daNm |
28 |
|
SIT24-N-GR1M
|
Sitex hub, drilled gr1,5 (1:8) |
|
35 mm |
2.1 daNm |
28 |
|
SIT24-NL-20
|
Sitex hub long, drilled ø20 H7 |
6,0 mm |
35 mm |
2.1 daNm |
28 |
|
SIT28-N-1
|
Sitex hub, ø1 H7 |
8,0 mm |
43 mm |
4.5 daNm |
34 |
|
SIT28-N-16
|
Sitex hub, drilled ø16 H7 |
5,0 mm |
43 mm |
4.5 daNm |
34 |
|
SIT28-N-25
|
Sitex hub, drilled ø25 H7 |
8,0 mm |
43 mm |
4.5 daNm |
34 |
|
SIT28-N-GR1
|
Sitex hub, drilled gr1 (1:8) |
2,4 mm |
43 mm |
4.5 daNm |
34 |
|
SIT28-N-GR2
|
Sitex hub, drilled GR2 (1:8) |
3,2 mm |
43 mm |
4.5 daNm |
34 |
|
SIT28-N-GR24
|
Sitex hub, drilled GR2-4 (1:8) 4 mm key 2 mm deep |
3,2, 4,0 mm |
43 mm |
4.5 daNm |
34 |
|
SIT32-N-1
|
Sitex hub, ø1 (25,4) 1/4 spline |
6,4 mm |
50 mm |
6 daNm |
40 |
|
SIT32-N-25
|
Sitex hub, drilled ø25 H7 |
8,0 mm |
50 mm |
6 daNm |
40 |
|
SIT32-N-30
|
Sitex hub, drilled ø30 H7 |
8,0 mm |
50 mm |
6 daNm |
40 |
|
SIT32-N-GR2
|
Sitex hub, drilled GR2 (1:8) |
3,2 mm |
50 mm |
6 daNm |
40 |
|
SIT32-N-GR3
|
Sitex hub, drilled GR3 (1:8) |
4,0 mm |
50 mm |
6 daNm |
40 |
|
SIT32-NL-24
|
Sitex nav, udboret ø24 H7 |
8,0 mm |
50 mm |
6 daNm |
40 |
|
SIT38-N-13/8
|
Sitex hub, ø 1.3/8 spline+pointed screw |
|
58 mm |
8.1 daNm |
44 |
|
SIT38-N-25
|
Sitex hub, drilled ø25 H7 |
8,0 mm |
58 mm |
8.1 daNm |
44 |
|
|
SIT38-N-32
|
Sitex hub, drilled ø32 H7 |
10,0 mm |
58 mm |
8.1 daNm |
44 |
|
SIT38-N-GR2
|
Sitex hub, drilled GR2 (1:8) |
3,2 mm |
58 mm |
8.1 daNm |
44 |
|
SIT38-N-GR3
|
Sitex hub, drilled GR3 (1:8) |
4,0 mm |
58 mm |
8.1 daNm |
44 |
|
SIT42-N-22
|
Sitex hub, drilled ø22 H7 |
6,0 mm |
65 mm |
10 daNm |
50 |
|
SIT42-N-25
|
Sitex hub, drilled ø25 H7 |
8,0 mm |
65 mm |
10 daNm |
50 |
|
SIT42-N-28
|
Sitex hub, drilled ø28 H7 |
8,0 mm |
65 mm |
10 daNm |
50 |
|
|
SIT42-N-3/4
|
Sitex hub, drilled ø3/4 |
4,8 mm |
65 mm |
10 daNm |
50 |
|
SIT42-N-7/8
|
Sitex hub, drilled ø7/8 |
6,4 mm |
65 mm |
10 daNm |
50 |
|
|
SIT42-N-GR2
|
Sitex hub, drilled GR2 (1:8) |
3,2 mm |
65 mm |
10 daNm |
50 |
|
SIT42-NL-24
|
Sitex hub, drilled ø24 |
8,0 mm |
65 mm |
10 daNm |
50 |
|
SIT42-NL-42
|
Sitex hub, drilled ø42 |
12,0 mm |
65 mm |
10 daNm |
50 |
|
SIT48-N-42
|
Sitex hub, drilled ø42 H7 |
12,0 mm |
68 mm |
14.2 daNm |
50 |
|
SIT48-N-48
|
Sitex hub, drilled ø48 H7 |
14,0 mm |
68 mm |
14.2 daNm |
50 |
|
SIT48-N-GR3
|
Sitex hub, drilled GR3 (1:8) |
4,0 mm |
68 mm |
14.2 daNm |
50 |
|
SIT48-NL-48
|
Sitex hub, drilled ø48 |
14,0 mm |
68 mm |
14.2 daNm |
50 |
|
SIT65-N-GR35
|
Sitex hub, drilled gr3,5 (1:8) |
4,8 mm |
96 mm |
38 daNm |
42 |
