NG10 4/2 valves Atos DKE with coil 24VDC

NG10 4/2 valves Atos DKE with coil 24VDC

Select variant
SELECT VARIANT
SELECT VARIANT
Partnumber Description Pressure T max. Voltage Current type Number of ways/positions
DKE1610-H DKE-1610-X24-DC Atos solenoid valve cetop5 210 bar 24 V DC 4/2
DKE1610/A-H DKE-1610/A-X24-DC Atos solenoid valve cetop5 210 bar 24 V DC 4/2
DKE1611-H DKE-1611-X24-DC Atos solenoid valve Cetop5 210 bar 24 V DC 4/2
DKE1613-H DKE-1613-X24-DC Atos solenoid valve cetop5 210 bar 24 V DC 4/2
DKE1614-H DKE-1614-X24-DC Atos solenoid valve cetop5 210 bar 24 V DC 4/2
DKE1630/2-H DKE-1630/2-X24-DC Atos solenoid valve cetop5 210 bar 24 V DC 4/2
DKE1630/2A-H DKE-1630/2A-X24-DC Atos solenoid valve cetop5 210 bar 24 V DC 4/2
DKE1631/2-H DKE-1631/2-X24-DC Atos solenoid valve cetop5 210 bar 24 V DC 4/2
DKE1631/2A-H DKE-1631/2A-X24-DC Atos solenoid valve cetop5 210 bar 24 V DC 4/2
DKE1631/2L-H DKE-1631/2L-X24-DC Atos solenoid valve Cetop5 210 bar 24 V DC 4/2
DKE1751/2-H DKE-1751/2-X24-DC Atos solenoid valve Cetop5 210 bar 24 V DC 4/3
Activation
Manual emergency override, Solenoid
Brand Name
Atos
Contamination level max.
20/18/15 - ISO 4406
Current type
DC
Flow rate nominal LMin
150
NG ISO-size
NG10
Oil viscocity recommended
15 - 100
Plug type
DIN EN 175301-803 Form A
Pressure T max.
210
Pressure max.
350
Standard ISO
ISO 4401
Temperature max.
+80
Temperature min.
-20
Torque tightening
15
Voltage
24
