Blind plugs for o-ring - SAE 3000 PSI - BS3 / 8339

Blind plugs for o-ring - SAE 3000 PSI - BS3 / 8339

Select variant
SELECT VARIANT
SELECT VARIANT
Partnumber Description Flange O-ring Pressure max.
BS3001 Flange plug 1/2" SAE3000 1/2 " 18.64X3.53 mm 350 bar
BS3002 Flange plug 3/4" SAE3000 3/4 " 24.99X3.53 mm 350 bar
BS3003 Flange plug 1" SAE3000 1 " 32.93X3.53 mm 320 bar
BS3004 Flange plug 1.1/4" SAE3000 1.1/4 " 37.69X3.53 mm 280 bar
BS3005 Flange plug 1.1/2" SAE3000 1.1/2 " 47.22X3.53 mm 210 bar
BS3006 Flange plug 2" SAE3000 2 " 56.75X3.53 mm 210 bar
BS3007 Flange plug 2 1/2" SAE3000 2.1/2 " 69,45x,3,53 mm 175 bar
BS3008 Flange plug 3" SAE3000 3 " 85,32x3,53 mm 160 bar
Flange SAE/DIN
3000 PSI
Shore
90
Standard ISO
ISO 6162-1
Standard SAE
SAE J518 Code 61
