Screw coupling male HSN - DN38 - G1.1/4" BSP female
Screw coupling male HSN - DN38 - G1.1/4" BSP female
Partnumber:
HSN-38-M-G20
Package size:
0 pcs
Min. order quantity is:
1 pcs
A
G 1.1/4 BSP
Brand Name
Stauff
Burst Pressure
1500 Bar
Connection
Screw
Disconnection
Screw
Field of application
Construction Machinery, Industrial Hydraulic
Flowrate nominal LMin
684 lpm
ISO size
38
L2
122,6 mm
L4
26,5 mm
Material
Carbon steel
Model code
QRC-HSN-38-M-G20-BP-W3
Pressure max.
350 bar
Pressurized connection
Allowed
Sealing material
NBR, Polyurethane
Size
1.1/2 "
Spillage
44,5 ml
Surface treatment
Zinc-Nickel plated
Temperature max.
+100 °C
Temperature min.
-25 °C
Thread DIN standard
DIN 3852-2-A
Thread inner
G 1.1/4 BSP
Package size
0 pcs
Barcode
51378
Gross weight
Kg
Net weight
2,435 Kg
Country of origin
deu
Intrastat code
84812010
Screw coupling male HSN - DN38 - G1.1/4" BSP female
